Features
The 180° tip angle design allows you to drill holes in a variety of applications that would be difficult with regular drills.
The thinning shape has excellent chip discharge and is made with a 30° twisted angle for enhanced cutting discharge and sharpness.
Double margin for stable holes in non-flat shapes.

Application
Diameter (D): 8
Groove length: 1.8 gal (32 L)
Total Length: 27.6 gal (80 L)
Shank diameter: 8 d

Specifications
Groove length: 1.3 inches (32 mm)
Total Length: 3.1 inches (80 mm)
Shank diameter: 0.3 inches (8 mm)
Outer Diameter: 0.3 inches (8 mm)
Surface treatment: UT COAT
UT coating
Twisting angle: 30°
Flat drill with 2 blades.

Note
Shank taper angle is estimate.
Please be sure to measure and check if interfere with work is required.
Please be careful of contact between the shank and work.

• Product Dimensions ‏ : ‎ 3.66 x 0.78 x 0.61 inches; 1.59 ounces
• Date First Available ‏ : ‎ December 18, 2024
• Manufacturer ‏ : ‎ ユニオンツール(Union Tool)
